Shrink Sleeve Converting Machines

  • From digital applications to non stop systems, Karlville fabricates the most complete Seamer product line in the industry that utilize the direct injection system with both wick & needle dispensers with proportional solvent to velocity control.

    All solvent features are controlled via the MMI. For film edge position accuracy, unwinds have digital edge guides. Likewise, the solvent applications has an optional micro edge guide for the most accurate solvent to edge control in the industry.

    Load cells for Unwinds and Rewinds feedback to PLC to assure accurate tension control for acceleration and deceleration as well as in constant high-speed mode.

    The Rewind comes standard with oscillation controlled via MMI for producing high quality rolls. A PLC control system with a user friendly MMI is integrated for easy operation. Turret Unwind + Rewind system are available for Non-Stop operation.


    Learn More »       Order Parts »
  • Cut

    The CUT Series uses a pillar type cutting block for high speed, accurate cutting to 350–450 pieces per minute (35-40 Meters per Minute).

    An AC Vector motor drives the cutting knife. A TD Converting Station features 75* and 90* horizontal perforation units.

    The PLC control system is standard. The servo film transport motor produces cut sleeves with an accuracy of +/-0.1mm.

    Learn More »       Order Parts »
  • The purpose of inspecting the seam is to provide the end user with a zero defect Shrink Sleeve oscillated roll. The inspection machine serves also to “doctor” printing defects. All models come standard with ACCUWEB EPC systems on the Rewind, oscillation on Rewind tied to EPC, automatic tension control via load cells on Unwind & Rewind and additional taper tension control module via PLC. Strobe and continuous perforations are optional accessories.

    Learn More »       Order Parts »
